| Rated air volume | 500m3/h |
| Pipe diameter of inlet | Φ125 |
| Oil drain caliber | DN25 |
| Motor power | 0.2KW |
| Voltage | 3*380V/50HZ |
| Size of equipment | 710(H)*515(L)*445(W) |
| Filter element size | 400*500(Primary stage H=100 / Secondary stage H=150) |
| Installation method | Mounted on the top or side bracket of the machine. |
| Applicable working condition | Suitable for slight oil mist 10mg and below, small air volume system |
