| Rated air volume | 12000-13800m3/h |
| Pipe diameter of inlet | Φ500mm |
| Oil drain caliber | DN32 |
| Motor power | 15KW |
| Voltage | 3*380V/20-50HZ(Variable Frequency) |
| Size of equipment | 3290(H)+400*1250(L)*2215(W) |
| Filter element size | 595*595*300(Primary / Secondary Stage)595*595*292(Tertiary Stage) |
| Installation method | Place on the side of the machine tool or on the side of the wall, connected by pipes. |
| Applicable working condition | Suitable for light oil mist (smoke) 10-30mg and below, medium and large air volume systems. |
