| Rated air volume | 800m3/h |
| Pipe diameter of inlet | Φ160mm |
| Oil drain caliber | DN25 |
| Motor power | 0.55KW |
| Voltage | 3*380V/50HZ |
| Size of equipment | 1356(H)*515(L)*445(W) |
| Filter element size | 400*500(Stage 1 H=100 / Stage 2 H=150 / Stage 3 H=200) |
| Installation method | Mounted on the top or side bracket of the machine. |
| Applicable working condition | Suitable for slight oil mist 10mg and below, small air volume system |
