| Rated air volume | 2000m3/h |
| Pipe diameter of inlet | Φ220mm |
| Oil drain caliber | DN32 |
| Motor power | 2.2kW |
| Voltage | 3*380V/20-50HZ(Variable Frequency) |
| Size of equipment | 2450(H)+310*740(L)*705(W) |
| Filter element size | 675*650*700(Primary Stage)675*650*300(Secondary Stage)675*650*292(Tertiary Stage) |
| Installation method | Place on the side of the machine tool or on the side of the wall, connected by pipes. |
| Applicable working condition | Suitable for medium oil mist (smoke) 20-50mg and below, medium and smallair volume systems. |
