| Rated air volume | 2000-2800m3/h |
| Pipe diameter of inlet | Φ220mm |
| Oil drain caliber | DN32 |
| Motor power | 2.2KW |
| Voltage | 3*380V/50HZ |
| Size of equipment | 2050(H)+310*660(L)*650(W) |
| Filter element size | 595*595*300(Primary Stage/Secondary Stage)595*595*292(Tertiary Stage) |
| Installation method | Place on the side of the machine tool or on the side of the wall,connected by pipes. |
| Applicable working condition | Suitable for slight oil mist 10-20mg and below, medium and small air volume systems. |
